9. Tools Menu
Image 9-11
Select window with <PiP ADJUST>
Image 9-12
9.6

PiP layout

Overview
•

PiP Save

• PiP rename layout
• PiP delete layout
9.6.1 PiP Save
What can be done ?
The active layout can be saved or "saved as".
When a new layout is saved it is added to the PiP select menu.
A fixed layout can be edited (re-sizing, re-positioning,...) but it can not be saved under its original name.
How to save a layout ?
1. Press MENU to activate the menu bar.
2. Press → to select the Tools item. (image 9-13)
3. Press ↓ to pull down the Tools menu.
4. Use ↑ or ↓ to select PiP layout.
5. Press → to pull down the menu.
6. Use ↑ or ↓ to select PiP save or save as.
7. Press ENTER.
If save as has been selected, a dialog box is displayed. (image 9-14)
Press ENTER to select the input field.
Use ← or → to enter the name and exit with BACK or MENU. (numeric values can be added with the remote control)
If save has been selected, a message box is displayed. (image 9-15)
96
Press <ENTER> to remove
R5976816 RLM R6+ PERFORMER 02/06/2006
