8. Image Menu
• The white balance happens only on Green.
Adjust until bright spots appear in the image.
Image 8-48
• The black balance happens on the three colors.
The PR and PB connector have to be removed from the input.
Adjust until noise appears in the image.
Image 8-49

8.11 AGC on Video

AGC
Automatic Gain Control: allows an automatic amplitude (gain) control of the incoming video signal
AGC is only for Video signals.
Enabling/disabling the AGC
1. Press MENU to activate the menu bar.
2. Press → to select the Image item.
3. Press ↓ to pull down the Image menu.
4. Use ↑ or ↓ to select AGC on Video.
5. Press → to pull down the menu.
6. Use ↓ or ↑ to enable or disable the AGC.
7. Press ENTER to confirm. (image 8-50)
A white bullet shows the active setting.
88 R5976816 RLM R6+ PERFORMER 02/06/2006
