This can also be done by using the dedicated PiP Adjust key on the RCU
Image 9-20
PiP adjust in case of 2-by-2 layout
A Data1 window has the focus, new settings will only affect Data1 window
B Video1 window has the focus, new settings will only affect Video1 window
PiP adjust
1. Press MENU to activate the menu bar.
2. Press → to select the Tools item. (image 9-21)
3. Press ↓ to pull down the Tools menu.
4. Use ↑ or ↓ to select PiP Adjust.
5. Press ENTER.
The menu disappears.
6. Press ENTER to move the focus to the next window (clockwise rotation).
If you press BACK or if you wait 5 seconds the menu is displayed again.
Image 9-21
How to adjust a window in the layout ?
1. Use the PiP Adjust key or function in the menu to choose the window to be adjusted.
2. Press ENTER.
All actions can be taken on the focused window.
R5976816 RLM R6+ PERFORMER 02/06/2006
9. Tools Menu
