9. Change the viewing order of the displayed images (z-order) with the ↑ and ↓ . (image 9-10)
Image 9-5
Source selection
Data on BNC's
Video selector
SDI
DVI
PC
Image 9-6
Pip Wizard step 2 : Resize this new window with
Image 9-8
Pip Wizard step 3 : Position this new window with
Image 9-9
Pip Wizard step 4 : Change the order of this new window with
Image 9-10
9.5

PiP remove window

How to remove a window ?
1. Press MENU to activate the menu bar.
2. Press → to select the Tools item.
3. Press ↓ to Pull down the Tools menu.
4. Use ↑ or ↓ to select PiP remove window. (image 9-11)
5. Press ENTER .
In the lower part of the screen appears a wizard. (image 9-12)
The selected window appears surrounded with a white frame.
6. Press PiP ADJUST to move the frame along the different windows until the desired window is selected.
7. Press ENTER to remove that window.
R5976816 RLM R6+ PERFORMER 02/06/2006
Pip Wizard step 1 : Select the source you want to display in the window...
Image 9-7
9. Tools Menu
95
