8. Image Menu
How to change the Phase ?
1. Press MENU to activate the menu bar. (image 8-10)
2. Press → to select the Image item.
3. Press ↓ to pull down the Image menu.
4. Use ↑ or ↓ to select settings.
5. Press → to pull down the menu.
6. Use ↓ or ↑ to select Phase.
7. Press ENTER .
A slider box appears.
8. Use ← or → to change the Phase and refine the jitter.
Or,
click in the input box and enter the desired value with the numeric keys.
Note: Don't mix up with wrong number of total pixels. If the jitter doesn't disappear with the phase adjustment, check the total
number of pixels. (Best image = pixel on pixel off pattern. For example: shut down screen of a PC)
Image 8-10
8.2.8

Noise reduction

About Noise reduction
Reduces noise and pixel jitter in all video sources.
How to change the Noise reduction ?
1. Press MENU to activate the menu bar. (image 8-11)
2. Press → to select the Image item.
3. Press ↓ to pull down the Image menu.
4. Use ↑ or ↓ to select settings.
5. Press → to pull down the menu.
6. Use ↓ or ↑ to select Noise reduction.
7. Press ENTER .
A slider box appears
8. Use ← or → to change the noise level.
The higher the value, the higher the noise reduction.
Or,
click in the input box and enter the desired value with the numeric keys.
