Key name
10
Lens control
11
VOL
12
Picture controls
13
DIGI ZOOM
14
FREEZE
15
PIP
16
ENTER
17
Cursor keys
18
BACK
19
EFFECTS
20
PIP ADJUST
21
RC operating indication
22
IR receiver
Led 1
Led 2
Led 3
4.2
Switching on
How to switch on.
1. Press the power switch to switch on the projector.
-
When '0' is pushed in, the projector is switched off.
-
When '1' is pushed in, the projector is switched on
The projector starts in standby mode, LED1 is red.
Starting image projection.
1. Press Standby key once on the local keypad or on the remote control.
Note: It may take about 60 seconds before image projection, i.e. no projection until the completion of several operations (soft-
ware initialization,...).
Note: If the Security mode is enabled, a text box will be displayed for PIN code entry, see Security setting in the Installation
menu
Note: If Identification screen is on, the Identification screen will be displayed during start up.
C
AUTION
displayed.
R5976816 RLM R6+ PERFORMER 02/06/2006
Description
use these buttons to obtain the desired ZOOM, SHIFT, FOCUS.
Used as lens shift left - right.
use these buttons to obtain the desired picture analog level.
allows a digital Zoom of a part of the image
press to freeze the projected image.
allows to activate the PICTURE IN PICTURE mode
to confirm an adjustment or selection in the MENU.
On the local keypad and the RCU, the ENTER button additionally accesses the PIP
window re-size function
Cursor Keys on RCU or on the local keypad : to make menu selections or to access the
menu bar.
to leave the selected menu or item (go upwards to previous menu).
not yet implemented
allows to select a PiP window and change its configuration on screen
lights up when a button on the remote control is pressed. (This is a visual indicator to
check the operation of the remote control)
IR receiver
Green
IR acknowledgement
Cool down sequence: flickers 60 seconds
after switching to standby
:
Pushing the standby key too long, might cause the projector to shut down right after an image is
4. Getting Started
Red
Standby
Hardware error
rescue program (software error)
