Image 8-50
The AGC can be disturbing in case of Macrovision encoded signals, therefore the AGC can be disabled (OFF)
at any time

8.12 Manual Gain Control

What can be done ?
When AGC on Video is disabled, the gain of the incoming video signal can be set manually. The manual gain control must be done
on an external pattern with white areas (grey scale bar pattern).
How to set the Manual Gain Control ?
1. Press MENU to activate the menu bar.
2. Press → to select the Image item.
3. Press ↓ to pull down the Image menu.
4. Use ↑ or ↓ to select Manual Gain Control. (image 8-51)
5. Press ENTER to confirm.
A scroll bar is displayed. (image 8-52)
6. Use ← or → to adjust the gain so that uniform white parts in the image are obtained.
Or,
use the numeric keys to enter the desired value.
Image 8-51
R5976816 RLM R6+ PERFORMER 02/06/2006
8. Image Menu
89
