Diagnostic LED Decoder
G=Green, R=Red, A=Amber
Checkpoint
MSB
0xEAh A
0xEEh A
0xEFh A
Runtime Phase / EFI Operating System Boot
0xF4h R
0xF5h R
0xF8h
A
0xF9h
A
0xFAh
A
Pre-EFI Initialization Module (PEIM) / Recovery
0x30h OFF OFF
0x31h OFF OFF
0x34h OFF
0x35h OFF
0x3Fh G
5.2.3

POST Error Messages and Handling

Whenever possible, the BIOS will output the current boot progress codes on the video screen.
Progress codes are 32-bit quantities plus optional data. The 32-bit numbers include class,
subclass, and operation information. The class and subclass fields point to the type of hardware
that is being initialized. The operation field represents the specific initialization activity. Based on
the data bit availability to display progress codes, a progress code can be customized to fit the
data width. The higher the data bit, the higher the granularity of information that can be sent on
the progress port. The progress codes may be reported by the system BIOS or option ROMs.
The Response section in the following table is divided into two types:
•
Pause: The message is displayed in the Error Manager screen, an error may be
logged to the NVRAM, and user input is required to continue. The user can take
immediate corrective action or choose to continue booting.
•
Halt: The message is displayed in the Error Manager screen, an error is logged to
the NVRAM, and the system cannot boot unless the error is resolved. The user
needs to replace the faulty part and restart the system.
Revision 1.3
LSB
R A OFF Flash Update
A A OFF Calling Int 19; one beep unless silent boot is enabled.
A A G Reserved for DXE Drivers use
A R R Entering Sleep state
A R A Exiting Sleep state
Operating system has requested EFI to close boot services
R R R
(ExitBootServices ( ) has been called)
Operating system has switched to virtual address mode
R R A
(SetVirtualAddressMap ( ) has been called)
Operating system has requested the system to reset (ResetSystem ()
R A R
has been called)
R R Crisis recovery has been initiated because of a user request
R A Crisis recovery has been initiated by software (corrupt flash)
G R R Loading crisis recovery capsule
G R A Handing off control to the crisis recovery capsule
G A A Unable to complete crisis recovery.
