Connectors and Jumper Blocks
A header on the server board provides an option to support two additional USB connectors. The
pin-out of the header is detailed in the following table.
Table 60. Optional USB Connection Header Pin-out (J1G1)
Signal Name
NC
GND
USB_FRONT1_INDUCTOR_DP
USB_FRONT1_INDUCTOR_DN
USB_FNT_PWR
6.6
Fan Headers
The server board supports five general purpose fan headers. All fan headers are 4-pin fan
headers (J7J1, J8D1, J4J1, and J6B1, J6J1) and have the same pin-out.
Table 61. Four-pin Fan Headers Pin-out (J4D1, J1K2,J7K1,J4K1J6B2)
Pin
Signal Name
1
Ground
2
Fan Power
3
Fan Tach
4
PWM
6.7
Miscellaneous Headers and Connectors
6.7.1
Back Panel I/O Connectors
Figure 32. Intel
Figure 33. Intel
Revision 1.3
Pin
1
3
5
7
9
Type
Power
GROUND is the power supply ground
Power
Fan Power
Out
FAN_TACH signal is connected to the Heceta* to monitor the FAN
speed.
Control
Pulse Width Modulation – Fan Speed Control signal
®
Server Board S3210SH-LX Back Panel I/O Connectors
®
Server Board S3210SH-LC / S3200SH-L Back Panel I/O Connectors
Intel® Server Boards S3200SH/S3210SH TPS
Signal Name
Key
GND
USB_FRONT2_INDUCTOR_DP
USB_FRONT2_INDUCTOR_DN
USB_FNT_PWR
Description
TBD
TBD
Pin
2
4
6
8
10
91
