Intel® Server Boards S3200SH/S3210SH TPS
•
Winbond* PC8374L super I/O chip interfaced to the ICH9R through LPC, supports the
following:
−
PS/2 keyboard/mouse
−
FDD
−
Six SATA II connectors
•
Five USB 2.0 ports: two ports on USB/LAN combo connectors at the rear of the server
board, two ports via onboard headers, and one port on an internal vertical connector
•
Two Gigabit Ethernet devices interfaced to the ICH9R to support two rear panel RJ45
connectors with integrated magnetics; one is through PCIe* x1, the other one is through
PCI32
•
ACPI power management
•
System monitoring (temperature, voltage, and fans)
•
VRD11 for processor
The server board supports the following feature set:
•
Processor and Front Side Bus (FSB) support
−
Supports Dual-Core Intel
processor 3100 series, Quad-Core Intel
Quad-Core Intel
−
Supports Intel
−
Supports Intel
®
•
Intel 3200/3210 Chipset components
®
−
Intel 3200/3210 Memory Controller Hub (MCH)
®
−
Intel ICH9R I/O Controller
®
−
Intel 6702 PXH-V PCI-X* Hub (LX board SKU only)
•
Memory System
−
Four DIMM sockets supporting DDR2 667/800MHz DIMMs
−
Data bandwidth per channel of 4.2GB/s or 8.4GB/s in dual channel when using
DDR2 667MHz
−
Support for up to two DDR2 channels for a total of four DIMMs (2 DIMMs /
channel) providing up to 8GB max memory capacity
−
Support for 512MB, 1GB and 2GB DRAM modules
Notes: 1. The server board does not support DDR2-533 DIMMs.
2. The server board does not support 256MB DIMMs.
•
I/O Subsystem
•
Clock
−
CK-505 compliant System Clock Generator
Revision 1.3
® ®
Xeon processor 3000 series, Dual-Core Intel
® ®
Xeon processor 3300 series.
®
dual-core technology
®
Extended Memory System 64 Technology (Intel
Server Board Overview
® ®
Xeon processor 3200 series, and
® ®
Xeon
®
EM64T)
3
