System BIOS
Setup Item
Clear System Event Enabled
Log
Disabled
FRB-2 Enable
Enabled
Disabled
O/S Boot Watchdog Enabled
Timer
Disabled
O/S Boot Watchdog
Power Off
Timer Policy
Reset
O/S Boot Watchdog 5 minutes
Timer Timeout
10 minutes
15 minutes
20 minutes
Console Redirection
System Information
4.3.2.4.1 Console Redirection Screen
The Console Redirection screen provides a way to enable or disable console redirection and to
configure the connection options for this feature.
To access this screen from the Main screen, select Server Management. Select the Console
Redirection option from the Server Management screen.
Revision 1.3
Options
Clears the System Event Log. All current entries will
be lost.
Note: This option will be reset to [Disabled] after a
reboot.
Fault Resilient Boot (FRB).
BIOS programs the BMC watchdog timer for
approximately 6 minutes. If BIOS does not complete
POST before the timer expires, the BMC will reset the
system.
BIOS programs the watchdog timer with the timeout
value selected. If the OS does not complete booting
before the timer expires, the BMC will reset the
system and an error will be logged.
Requires OS support or Intel Management Software.
If the OS watchdog timer is enabled, this is the system
action taken if the watchdog timer expires.
[Reset] - System performs a reset.
[Power Off] - System powers off.
If the OS watchdog timer is enabled, this is the
timeout value BIOS will use to configure the watchdog
timer.
View/Configure console redirection information and
settings.
View system information
Intel® Server Boards S3200SH/S3210SH TPS
Help Text Comments
Takes user to Console
Redirection Screen.
Takes user to System
Information Screen.
