System BIOS
4.3.1.4 Menu Selection Bar
The Menu Selection Bar is located at the top of the screen. It displays the major menu
selections available to the user.
4.3.2

Server Platform Setup Screens

The sections below describe the screens available for the configuration of a server platform. In
these sections, tables are used to describe the contents of each screen. These tables follow the
following guidelines:
•
The text and values in the Setup Item, Options, and Help columns in the tables are
displayed on the BIOS Setup screens.
•
Bold text in the Options column of the tables indicates default values. These values are
not displayed in bold on the setup screen. The bold text in this document is to serve as a
reference point.
•
The Comments column provides additional information where it may be helpful. This
information does not appear in the BIOS Setup screens.
•
Information in the screen shots that is enclosed in brackets (< >) indicates text that
varies, depending on the option(s) installed. For example <Current Date> is replaced by
the actual current date.
•
Information that is enclosed in square brackets ([ ]) in the tables indicates areas where
the user needs to type in text instead of selecting from a provided option.
4.3.2.1 Main Screen
The Main screen is the screen that is first displayed when BIOS Setup is entered, unless an
error has occurred. If an error has occurred, the Error Manager screen will be displayed instead.
