Intel® Server Boards S3200SH/S3210SH TPS
®
6.2 Intel Riser Card for L SKU
®
The Intel Server Board S3200SH-L has a PCIe* x16 to PCIe* x16 riser card.
This riser card is designed to be populated with PCIe* x16 slot on the Intel
S3200SH-L. The physical layout to the PCIe* x16 slot on the riser card is PCIe* x8.
This riser card is designed for populating the Intel
Server Chassis SR1530.
6.3

SMBus Connector

Pin
1 SMB_DAT_5V_BP
2 GND
3 SMB_CLK_5V_BP
4 TP_BP_I2C_HRD_4
6.4

Front Panel Connector

A standard SSI 24-pin header is provided to support a system front panel. The header contains
reset, NMI, power control buttons, and LED indicators. The following table details the pin-out of
this header.
FP_PWR_LED_P1
KEY
FP_GPIO_GRN_BLNK_HDR
P3V3
LED_HD_N
FP_SW_ON_HDR_N
GND
FP_RST_FPHDR_N
GND
FP_ID_BTN_N
TP_FM_ONE_WIRE_TEMP_SENSOR
TP_SSI_PIN23
86

Table 50. SMBus Connector Pin-out (J1E1)

Signal Name

Table 51. Front Panel 24-Pin Header Pin-out (J1K2)

Signal Name
Connectors and Jumper Blocks
®
Server Board S3200SH-L into the Intel
Data Line
GROUND
Clock Line
Test Point
Pin Signal Name
1 P3V3_STBY
3 P5V_STBY
5 FP_ID_LED_N
7 TP_SSI_PIN8
9 TP_SSI_PIN10
11 FP_NIC1_ACT_LED_R_N
13 NIC1_LINK_1_N
15 TP_SSI_PIN16
17 TP_SSI_PIN18
19 FP_Intruder_HDR_N
21 FP_NIC2_ACT_LED_R_N
23 NIC2_LINK_UP_N
®
Server Board
®
Description
Pin
2
4
6
8
10
12
14
16
18
20
22
24
Revision 1.3
