Intel® Server Boards S3200SH/S3210SH TPS
•
System Management
−
Processor on die temperature monitoring through PECI interface
−
Board temperature measurement
−
Fan speed monitoring and control
−
Voltage monitoring
−
IPMI-based server management
•
Battery
−
Socketed, Lithium coin cell-3V
•
Sockets
−
One LGA775 processor (Socket-T)
−
Four DDR2 DIMM Sockets
−
One battery (CR2032)
•
Legacy Interfaces
−
Serial
−
Floppy
−
PS2 keyboard
−
PS2 mouse
•
Power Management Modes Supported (ACPI Sleep states)
−
S0 – Full on
−
S1 - Power-on-suspend
−
S4 – Suspend to Disk
−
S5 – Soft on/off
•
Connectors List
−
Four 240-Pin DDR2 DIMM connectors
−
PCIe*, PCI-X*, and PCI connectors (see SKU specific information)
−
One RJ45 Connectors with magnetics and LEDs
−
One stacked RJ45 with magnetics and LEDs and two-USB combo connector
−
34 pin floppy drive connector
−
One serial port headers
−
Dual stacked PS/2 keyboard and mouse connector
−
USB connectors (two stacked on the rear panel and three on the server board
headers)
−
SSI-EEB ATX power connectors
−
One 4-pin auxiliary power connector
−
One stacked DB-15 VGA/DB-9 Serial port connector
−
Six 7-pin SATA II connectors
−
60-pin XDP connector
−
Four 4-pin, 0.10" pitch fan headers
−
24-Pin, SSI-EEB, front panel connector
Revision 1.3
Server Board Overview
5
