Server Board Overview
One 4-pin SATA RAID Key
One 2-pin intrusion detection
BIOS
EFI BIOS
Power Management
Support for Power Management of all capable components
ACPI compliant motherboard and BIOS
Sleep Switch and dual mode LED indicator
Manufacturing
Surface mount technology. Single sided assembly for LC/V board SKUs and
double sided assembly for the LX board SKU
6 layer PCB
Form Factor
ATX 2.0, 12'' x 9.6'', 1U thermally optimized, and SSI TEB Rev 2.11 compatible.
Universal Serial Bus 2.0 (USB)
Two external USB ports (located at the rear panel) with an additional internal
header providing two optional USB ports for front panel support
Supports wake-up from sleeping states S1 and S4 (S3 is not supported)
Supports legacy keyboard/mouse connections when using a PS2-USB dongle
LPC (Low Pin Count) bus segment with one embedded device
Super I/O controller (SMSC* SCH5027D) providing all PC-compatible I/O (floppy,
serial, keyboard, mouse, two serial com ports) and integrated hardware
monitoring.
SSI-compliant connectors for SSI interface support
Standard 24-pin SSI front panel, 2x12 main power connector, and 2x4 CPU power
connector
Fan Support
5 general purpose 4-pin fan headers
Diagnostic LEDs to display POST code indicators during boot
Onboard SATA RAID
®
Intel
Matrix Storage Technology supports software SATA RAID 0, 1, 10 and 5
Microsoft Windows
The following figure shows the board layout of the LX board SKU. Each connector and major
component is identified by letter (shown in Table 1).
6
One 4-pin processor fan header (active heat sink required)
Four 4-pin system fan headers: SYS FAN1, SYS FAN2 and SYS
FAN3 for Intel high density applications to support Intel
System SR1530SH; SYS FAN4 is for use in the Intel
Chassis SC5299-E
*
driver support only.
Intel® Server Boards S3200SH/S3210SH TPS
®
Server
®
Entry Server
;
Revision 1.3
