Functional Architecture
The system is designed to populate any rank on either channel, including either degenerate
single channel case.
DIMM and memory configurations must adhere to the following:
•
DDR2 667/800, un-buffered, DDR2 DIMM modules
•
DIMM organization: x64 non-ECC or x72 ECC
•
Pin count: 240
•
DIMM capacity: 512 MB, 1 GB and 2 GB DIMMs
•
Serial PD: JEDEC Rev 2.0
•
Voltage options: 1.8 V
•
Interface: SSTL2

Table 10. Memory Bank Labels and DIMM Population Order

Location
28
DIMM Label
J8J1 (DIMM_1A)
J8J2 (DIMM_2A)
J9J1 (DIMM_1B)
J9J2 (DIMM_2B)
Intel® Server Boards S3200SH/S3210SH TPS
Channel Population Order
A 1
A 3
B 2
B 4
Revision 1.3
