Intel
Server Board SE7520JR2
Tested Hardware and Operating System List
Revision 7.0
July 2007
Enterprise Platforms and Services Marketing

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SE7520JR2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intel SE7520JR2

Summary of Contents for Intel SE7520JR2

  • Page 1 ® Intel Server Board SE7520JR2 Tested Hardware and Operating System List Revision 7.0 July 2007 Enterprise Platforms and Services Marketing...
  • Page 2 No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right.

  • Page 3: Table Of Contents

    Intel® Server Board SE7520JR2 Table of Contents Table of Contents 1. Introduction .......................... 1 Test Overview......................2 1.1.1 Basic Installation Testing ..................2 1.1.2 Adapter / Peripheral Compatibility and Stress Testing ..........2 Pass/Fail Test Criteria ..................... 3 2. Base System Definitions ..................... 5 3.

  • Page 4: Introduction

    Introduction Introduction This document is intended to provide users of the Intel® Server Board SE7520JR2 with a list of the operating systems, adapter cards, and peripherals tested by Intel on this server platform. This document will continue to be updated as new adapters, peripherals, and operating systems are tested or until the Intel®...

  • Page 5: Test Overview

    • Intel will NOT provide support for issues related to use of any add-in adapters or peripherals installed in the server system when an operating system that received basic installation testing only is in use.

  • Page 6: Pass/Fail Test Criteria

    Intel will enable vendors to provide driver support for add-in adapters using these operating systems. • Intel will go through some of the steps to achieve certification to ensure its customers do not run across any problems, but the actual certification is the responsibility of the individual customer.
  • Page 7 Introduction Intel® Server Board SE7520JR2 Application software installed and executed normally. • Hardware compatibility tests ran to completion without error. • Test software suites executed successfully Test and data files were created in the correct directories without error. Files copied from client to server and back compare to the original with zero errors reported.

  • Page 8: Base System Definitions

    The adapters and peripherals specified in this document may or may not have been tested on all available board/riser combinations that make up the SE7520JR2 product family. However, Intel will provide support for the adapters and peripherals listed when used within this family of products This table is updated when a new test run is performed and a new product/system software combination was used.

  • Page 9: Supported Operating Systems

    Intel® Server Board SE7520JR2 Supported Operating Systems The following table provides a list of supported operating systems for the Intel® Server Board SE7520JR2. Each of the listed operating systems was tested for compatibility with Intel® server board SE7520JR2 base system configuration listed in Section 2 of this document.
  • Page 10 Intel® Server Board SE7520JR2 Supported Operating Systems Base System Notes Operating System Configuration Tested & Type of Testing Compatibility & Stress Base Config # - 5, 6 Novell NetWare* 6.5, Service Pack 4 PXE OS installation is not supported Compatibility & Stress Base Config # - 1, 2, 3, Novell NetWare* 5.1, Service Pack 7...

  • Page 11: Operating System Certifications

    Intel® Server Board SE7520JR2 Operating System Certifications Listed below are the operating systems that Intel will certify with the Intel® server board SE7520JR2. However, the customer is responsible for their own certification from the individual operating system vendors. In many cases, the customer may leverage their operating system certifications from Intel’s testing.

  • Page 12: Adapters And Peripherals

    IHVT (IHV Tested) peripherals listed in this document, regardless of whether this adapter or peripheral was tested in an Intel lab or not. IHV test reports remain the property of the IHV (Intel cannot provide copies of these reports). Any variations to the standard adapter installation process or to expected adapter functionality are documented in the Installation Guidelines section of this document.
  • Page 13 Intel® Server Board SE7520JR2 Testing of adapters cards normally is performed with unused add-in adapters and onboard controller expansion ROMs disabled in BIOS Setup. Intel recommends that customers disable the option ROM for add-in controllers and/or the on-board controllers when not booting from the controller or needing to use its built in utilities.

  • Page 14: Pci Scsi Raid

    Intel® Server Board SE7520JR2 Adapters and Peripherals Manufacturer Model Number Model Name Interface Comments PCI SCSI RAID Adaptec ASR-2200S ASR-2200S PCI-64/66 BIOS:4.2-0 1,2,3,4, 3,4,5 1,2,3,4, 1,3,4,5, 1,3,4,5, 1,3,4,5, 2,3,4,5 2,3,4,5 FW:7349 Adaptec ASR-2120S ASR-2120S PCI-64/66 ICP vortex GDT8514RZ GDT8514RZ PCI-64/66 BIOS:7.05C...
  • Page 15 Adapters and Peripherals Intel® Server Board SE7520JR2 Manufacturer Model Number Model Name Interface Comments Adaptec AAR2810SA AAR2810SA PCI-64/66 AMCC/3ware 9500S-8 9500S-8 PCIX-66 BIOS:BE9X 3,4,5,6 2,3,4,5, 2,3,4,5, 2,3,4,5 2.03.01.051 FW:FE9X 2.06.00.009 AMCC/3ware 9500S-12 9500S-12 PCI-X66 AMCC/3ware 9500S-12ML 9500S-12ML PCI-X66 AMCC/3ware 9500S-4LP...

  • Page 16: Pci Scsi

    Intel® Server Board SE7520JR2 Adapters and Peripherals Manufacturer Model Number Model Name Interface Comments PCI SCSI Adaptec ASC-29160 ASC-29160 PCI-64/66 BIOS:3.10.0 1,2,3,4, 3,4,5 1,3,4,5, 1,2,3,4, 1,2,3,4, 1,2,3,4, 2,3,4,5 2,3,4,5 Adaptec ASC-29160LP ASC-29160LP PCI-64/66 Adaptec ASC-29160N ASC-29160N PCI-64/66 Adaptec ASC-29320ALP ASC-29320ALP PCI-X133 BIOS:4.30.0...

  • Page 17: Pci Mromb

    Adapters and Peripherals Intel® Server Board SE7520JR2 Manufacturer Model Number Model Name Interface Comments LSI Logic 3442x 3442x PCI-X133 BIOS:6.06.03.00F 4,5,6 4,5,6 W:0.07.07.00 PCI MROMB Intel SRCZCRX SRCZCRX PCI-X133 BIOS:H431 1,2,3,4, 1,3,4,5, 1,2,3,4, 2,3,4,5, 1,2,3,4, 2,3,4,5 3,4,5,6 2,3,4,5 FW:414D LSI Logic...

  • Page 18: Pci Infiniband

    Intel® Server Board SE7520JR2 Adapters and Peripherals Manufacturer Model Number Model Name Interface Comments QLogic QLA2200L QLA2200L PCI-64/66 FW 1.61 QLogic QLA2200/66 QLA2200/66 PCI-64/66 QLogic QLA2342 QLA2342 PCI-X133 BIOS:1.43 1,2,3,4, 3,4,5 1,2,3,4, 1,2,3,4, 1,2,3,4, 1,2,3,4, 2,3,4,5 2,3,4,5 FW:3.02.28 QLogic QLA2340...

  • Page 19: Modems

    Adapters and Peripherals Intel® Server Board SE7520JR2 Manufacturer Model Number Model Name Interface Comments Intel PWLA8490MF PRO/1000MF Gigabit PCI-X133 Server Adapter Intel PWLA8490XT PRO/1000XT Gigabit PCI-X133 1,2,3,4, 3,4,5 1,2,3,4, 1,3,4,5, 1,3,4,5, 1,3,4,5, 3,4,5 3,4,5,6 Server Adapter Intel PWLA8490XF PRO/1000XF Gigabit...

  • Page 20: Keyboard/Mouse

    Intel® Server Board SE7520JR2 Adapters and Peripherals Manufacturer Model Number Model Name Interface Comments 4.10 Keyboard/Mouse Keytronic E06101USB-C E06101USB-C Keyboard with 2 1.2,3,4, 3,4,5,6 1.2,3,4, 1,2,3,4, 2,3,4,5, 1,2,3,4, 2,3,4,5, 2,3,4,5 port USB hub Keytronic PRO Pilot PRO Pilot PS/2 1,2,3,4,...

  • Page 21: Dvd Drives

    Adapters and Peripherals Intel® Server Board SE7520JR2 Manufacturer Model Number Model Name Interface Comments 22P6991 24x10x24 IDE/Slimline CD-RW / DVD- 1,2,3,4, 3,4,5,6 1,2,3,4, 2,3,4,5, 2,3,4,5, 2,3,4,5, 2,3,4,5, 2,3,4,5 ROM combo Panasonic UJDA750 UJDA750 IDE/Slimline CD-RW / DVD- 3,4,5,6 3,4,5,6 3,4,5,6...

  • Page 22: Removable Drives

    Intel® Server Board SE7520JR2 Adapters and Peripherals Manufacturer Model Number Model Name Interface Comments Sony SDX-560V AIT-2T (80GB) ATAPI ATAPI IHVT* IHVT* * See Section 6.3 Tape Drive Sony SDX-700V AIT-3 (100GB) SCSI SCSI IHVT* IHVT* * See Section 6.3...
  • Page 23 Adapters and Peripherals Intel® Server Board SE7520JR2 Manufacturer Model Number Model Name Interface Comments Diamond=ATI Stealth S80 RADEON 9200SE PCI-32/33 =ATI Radeon 9200 Revision 7.0...

  • Page 24: Hard Disk Drives

    Note that not all hard drives were tested under all operating systems. The following notation is used in the tested hard drives table below to indicate the support level that Intel provides for a particular hard drive with a particular operating system: This hard drive has been tested and is supported under the operating system Number (i.e.
  • Page 25 Hard Disk Drives Intel® Server Board SE7520JR2 Tested Drive size Manufacturer Model Number Product Family Interface Operating Notes (GB) Systems SCSI Hard Drives Fujitsu MAP3147NC SCSI/U320 147GB 1,2,3,5,7 Fujitsu MAP3367NC SCSI/U320 36GB Fujitsu MAP3735NC SCSI/U320 73GB Fujitsu MAS3735NC SCSI/U320 73GB...
  • Page 26 Intel® Server Board SE7520JR2 Hard Disk Drives Tested Drive size Manufacturer Model Number Product Family Interface Operating Notes (GB) Systems Maxtor 8D073J0 Atlas 10K V U320/SCA 73GB Maxtor 8D147J0 Atlas 10K V U320/SCA 147GB Maxtor 8D300L0 Atlas 10K V U320/68pin...
  • Page 27 Hard Disk Drives Intel® Server Board SE7520JR2 Tested Drive size Manufacturer Model Number Product Family Interface Operating Notes (GB) Systems Seagate ST3146707LW Cheetah 10K.7 U320/68pin 147GB Seagate ST373453LC Cheetah 15K.3 U320/SCA 1,2,3,5,6,7,9, 73GB 10,12,13 Seagate ST336753LC Cheetah 15K.3 U320/SCA 36GB...
  • Page 28 Intel® Server Board SE7520JR2 Hard Disk Drives Tested Drive size Manufacturer Model Number Product Family Interface Operating Notes (GB) Systems Maxtor 7B250S0/7L250S0 Maxline III SATA/150 7200 250GB Seagate ST3160023AS Barracuda SATA/150 1,2,3,5,6,9,10 7200 160GB 7200.7 ,12,13 Seagate ST3120023AS Barracuda SATA/150...
  • Page 29 Hard Disk Drives Intel® Server Board SE7520JR2 Tested Drive size Manufacturer Model Number Product Family Interface Operating Notes (GB) Systems Hitachi IC35L060AVV207 Deskstar ATA/100 7200 60GB 180GXP Hitachi IC35L030AVV207 Deskstar ATA/100 7200 30GB 180GXP Hitachi HDS722516VLAT80 Deskstar 7K250 ATA/100 1,2,3,5,6,9,10...

  • Page 30: Installation Guidelines & Test Notes

    Intel and non-Intel server boards. A newer kernel version (2.6.5-7.75-smp or newer) appears to fix the issue. Intel policy provides server board support only for the major releases of non- enterprise Linux products. This is because interim kernel releases for these operating systems require recompiling the Intel RAID, fiber channel, ROMB, and similar non-shipping drivers.
