Intel® Server Boards S3200SH/S3210SH TPS
4.3.2.4 Server Management Screen
The Server Management screen provides fields to configure several server management
features. It also provides an access point to the screens for configuring console redirection and
displaying system information.
To access this screen from the Main screen, select the Server Management option.
Advance
Main
d
Assert NMI on SERR
Assert NMI on PERR
Resume on AC Power Loss
Clear System Event Log
FRB-2 Enable
O/S Boot Watchdog Timer
O/S Boot Watchdog Timer Policy
O/S Boot Watchdog Timer Timeout
► Console Redirection
► System Information
Figure 20. Setup Utility — Server Management Configuration Screen Display
Table 29. Setup Utility — Server Management Configuration Screen Fields
Setup Item
Assert NMI on SERR
Enabled
Disabled
Assert NMI on PERR
Enabled
Disabled
Resume on AC Power
Stay Off
Loss
Last state
Reset
62
Security Server Management
Options
On SERR, generate an NMI and log an error.
Note: [Enabled] must be selected for the Assert NMI
on PERR setup option to be visible.
On PERR, generate an NMI and log an error.
Note: This option is only active if the Assert NMI on
SERR option is [Enabled] selected."
System action to take on AC power loss recovery.
[Stay Off] - System stays off.
[Last State] - System returns to the same state before
the AC power loss.
[Reset] - System powers on.
Boot Options
Enabled / Disabled
Enabled / Disabled
Stay Off /Last state/ Reset
Enabled / Disabled
Enabled / Disabled
Enabled / Disabled
Power off / Reset
5 minutes / 10 minutes / 15 minutes / 20 minutes
Help Text
System BIOS
Boot Manager
Comments
Revision 1.3
