System BIOS
Setup Item
Discard Changes
Load Default Values
Save as User Default
Values
Load User Default
Values
4.3.2.9.1 Fan Speed Control Methodology
®
Intel Server Boards S3200SH and S3210SH have an integrated BMC, which provides
advanced fan speed control features compared to previous platforms. The integrated BMC FW
and FRUSDR provide HW monitoring, fan speed control, and system management features.
Intel released FRUSDRs will contain the fan speed control support for Intel server chassis by
default. The supported chassis are:
• ®
Intel Server Chassis SR1530
• ®
Intel Entry Server Chassis SC5299-UP
For any third party non-Intel chassis, if a customer wants to implement similar fan speed control
to the system fans attached inside the third party chassis, they need to edit the master.cfg file
included in the FRUSDR update package. The FRUSDR will manage the system fans to work at
the speed that the customer inputs.
Intel will publish a third party chassis fan speed control white paper to guide customers on how
to edit the master.cfg file to have fan speed control functions for the third party chassis. Without
doing so, the third party chassis fan speed cannot be controlled as the FRUSDR does not
recognize the fans, and does not know what speed the fans should operate at under which
environment temperatures.
Revision 1.3
Help Text
Discard changes made since the last save
changes operation was performed.
Load factory default values for all BIOS Setup
Utility options.
The [F9] key can also be used.
Save current BIOS Setup Utility values as
custom user default values. If needed, the user
default values can be restored via the Load
User Default Values option below.
Note: Clearing CMOS or NVRAM will cause the
user default values to be reset to the factory
default values.
Load user default values.
Intel® Server Boards S3200SH/S3210SH TPS
User is prompted for confirmation only
if any of the setup fields were
modified.
User is prompted for confirmation.
User is prompted for confirmation.
User is prompted for confirmation.
Comments
