Intel® Server Boards S3200SH/S3210SH TPS
Advanced
Memory Configuration
Total Memory
Effective Memory
Current Configuration
Current Memory Speed
DIMM Information
DIMM_A1
DIMM_A2
DIMM_B1
DIMM_B2
Memory Correction
Figure 14. Setup Utility — Memory Configuration Screen Display
Setup Item
Total Memory
Effective Memory
Current Configuration
54
<Total Physical Memory Installed in System>
<Total Effective Memory>
< Single Channel/Dual Channel >
<Speed that installed memory is running at.>
Installed/Not Installed/Failed
Installed/Not Installed/Failed
Installed/Not Installed/Failed
Installed/Not Installed/Failed
ECC/Non-ECC
Table 23. Setup Utility — Memory Configuration Screen Fields
Options Help Text
Information only. The amount of memory
available in the system in the form of
installed DIMMs, in units of MB or GB.
Information only. The amount of memory
available to the operating system in MB or
GB.
The Effective Memory is the difference
between Total Physical Memory and the
sum of all memory reserved for internal
usage. This difference includes the sum of
all DIMMs that failed Memory Test during
POST.
Information only. Displays one of the
following:
• Dual Channel: System memory is
configured for optimal performance and
efficiency.
• Single Channel: System memory is
functioning in a special, reduced
efficiency mode.
System BIOS
Comments
Revision 1.3
