Intel® Server Boards S3200SH/S3210SH TPS
Diagnostic LED Decoder
G=Green, R=Red, A=Amber
Checkpoint
MSB
0x25h OFF
0x26h OFF
0x27h OFF
0x28h G OFF
PCI Bus
0x50h OFF
0x51h OFF
0x52h OFF
0x53h OFF
0x54h OFF
0x55h OFF
0x56h OFF
0x57h OFF
USB
0x58h G
0x59h G
ATA / ATAPI / SATA
0x5Ah G
0x5Bh G
SMBUS
0x5Ch G
0x5Dh G
Local Console
0x70h OFF
0x71h OFF
0x72h OFF
Remote Console
0x78h G
0x79h G
0x7Ah G
Keyboard (PS2 or USB)
0x90h R OFF
0x91h R OFF
0x92h R OFF
0x93h R OFF
0x94h R
0x95h R
Mouse (PS2 or USB)
0x98h A OFF
0x99h A OFF
0x9Ah A OFF
0x9Bh A OFF
Revision 1.3
LSB
G R G Configuring memory parameters in the memory controller
G A OFF Optimizing memory controller settings
G A G Initializing memory, such as ECC init
R OFF Testing memory
R OFF R Enumerating PCI busses
R OFF A Allocating resources to PCI busses
R G R Hot Plug PCI controller initialization
R G A Reserved for PCI bus
A OFF R Reserved for PCI bus
A OFF A Reserved for PCI bus
A G R Reserved for PCI bus
A G A Reserved for PCI bus
R OFF R Resetting USB bus
R OFF A Reserved for USB devices
R G R Begin SATA bus initialization
R G A Reserved for ATA
A OFF R Resetting SMBUS
A OFF A Reserved for SMBUS
R R R Resetting the video controller (VGA)
R R A Disabling the video controller (VGA)
R A R Enabling the video controller (VGA)
R R R Resetting the console controller
R R A Disabling the console controller
R A R Enabling the console controller
OFF R Resetting the keyboard
OFF A Disabling the keyboard
G R Resetting the keyboard
G A Enabling the keyboard
G OFF R Clearing keyboard input buffer
G OFF A Instructing keyboard controller to run Self Test (PS2 only)
OFF R Resetting the mouse
OFF A Detecting the mouse
G R Detecting the presence of mouse
G A Enabling the mouse
Error Reporting and Handling
Description
