System BIOS
Setup Item
Current Memory
Speed
DIMM_#
Memory Correction
ECC
Non-ECC
4.3.2.2.3 SATA Controller Screen
The ATA Controller screen provides fields to configure SATA hard disk drives. It also provides
information on the hard disk drives that are installed.
To access this screen from the Main screen, select Advanced | SATA Controller.
Advanced
SATA Controller Configuration
Onboard SATA Controller
Configure SATA as
► SATA Port 0
► SATA Port 1
► SATA Port 2
► SATA Port 3
► SATA Port 4
► SATA Port 5
Figure 15. Setup Utility — ATA Controller Configuration Screen Display
Revision 1.3
Options Help Text
Enabled / Disabled
IDE / AHCI/ RAID
Not Installed/<Drive Info.>
Not Installed/<Drive Info.>
Not Installed/<Drive Info.>
Not Installed/<Drive Info.>
Not Installed/<Drive Info.>
Not Installed/<Drive Info.>
Intel® Server Boards S3200SH/S3210SH TPS
Information only. Displays speed the
memory is running at.
Displays the state of each DIMM socket
present on the board. Each DIMM socket
field reflects one of the following possible
states:
Installed: There is a DIMM installed in this
slot.
Not Installed: There is no DIMM installed
in this slot.
Failed: The DIMM installed in this slot is
faulty / malfunctioning.
Comments
