Figure 48. The Cable Connection In Case Of Providing Rear External Vhdci Scsi Port - Intel SRSH4 - Server Platform - 0 MB RAM Service Manual

3. In case of providing SCSI (VHDCI) interface onto rear external port
Remove "
SCSI 3CONN TERM (160M)(001)
basic configuration. Instead by using "
"Accessory kit of system unit", connect between "ch.B port on Baseboard" and rear external SCSI
(VHDCI) interface port.
Note) In case of this configuration, the removed "
had been connected to Internal peripherals needs other SCSI port which is like a optional PCI SCSI
cards.
Cable names
A U320 SCSI CABLE (104) BB-HDDBA
B BOX-34P CABLE(BEND1)
C FDD CABLE(025)
D IDE SIGNAL CABLE(BEND1)
E HOT-PLUG PCI 28PIN CABLE(0.16)
F FAN SIGNAL CABLE(040)
G IPMB CABLE(035)
H ICMB CABLE(035)
I F/P USB CABLE(160)
J F/P SERIAL CABLE(160)
K OPEN SENSER CABLE(040)
L 140RC-4 EXT SCSI CBL

Figure 48. The cable connection in case of providing rear external VHDCI SCSI port

" which had been connected to ch.B on Baseboard at
0.8MM Pitch EXT. SCSI CABLE (053)
SCSI 3CONN TERM (160M)(001)
Part Numbers Qty.
804-063107-1040 1
808-744465-501 1
804-062337-525 1
804-062050-501 1
804-062719-516 1
804-062929-040 1
804-062930-035 1
804-062931-035 1
804-062932-160 1
804-062933-160 1
804-062937-040 1
804-062722-0531 1
" which is attached in
Dimensions
SCSI(ch.A) on Baseboard – HDD
1040mm
Cage
705mm For signals of Front Panel board
250mm FDD signals
Signals for CDROM(master) and
500mm
extension devices(slave)
165mm For signals of HPIB
345mm For signals of FAN BP
370mm IPMB signals for HDD cage
355mm ICMB signals
595mm USB signals on Front Panel board
610mm COM signals on Front Panel board
420mm Chassis intrusion
SCSI(ch.B) on Baseboard –
530mm
external VHDCI SCSI
" cable which
L
Descriptions
82
