Installing a Power Supply Module

To install a power supply module:
1. Remove the bezel (page 28).
2. If present, remove the filler panel from the vacant slot.
3. Slide the power supply module into the vacant slot until you feel resistance.
CAUTION
The module engaging its connector causes the resistance. To avoid damaging
the module, do not tilt or twist the power supply module as you push it into the
connector.
4. Push the module into the bay until the locking tab snaps into place.
The green LED on the power supply module should be illuminated.
5. Tighten the captive screw that retains the power supply module.
6. Install the bezel.
56
