1 Introduction
This document provides a detailed description of the chassis and system level features of the
®
Intel
SRMK2 Internet Server. This system is a high-density rackmount server consisting of a
1U chassis and the SRMK2 serverboard. The server will come in two models: A SCSI based
system (SRMK2S) and a SCSI based system with a –48V DC power supply (SRMK2D). Since
both of these systems are based off of the SRMK2S product, this guide has been written to
represent the SRMK2S. Notes and additions have been added to identify discrepancies between
the SRMK2S and the SRMK2D.
Table 1 provides a list and brief description of the SRMK2 Internet Server's key features.
Table 1: Intel
Feature
1U chassis
Weight
Power supply
Cooling
Rackmounting
Hard disk capacity
Peripheral bays
Peripheral Interfaces
Microprocessor
Memory capacity
LAN support
Add-in card support
System management
BIOS
Intel ® SRMK2 Internet Server Technical Product Specification
®
SRMK2S Internet Server key features
Description
1.70" (height) x 16.75" (width behind bezel) x 24" (depth)
Approximately 30lbs in-box shipping weight
Single 200W AC power supply (200W DC supply comes with the SRMK2D)
Nine system fans (Eight 40mm and one 17mm)
Two midmount and Front mounting brackets or sliding rails (optional)
Support for two 1" U160 Hot Swappable SCSI hard drives for internal
configuration along with an external SCSI channel for external drives
Single standard slim diskette drive included with system. Optional slim-line
CD-ROM drive available (works in conjunction with the standard diskette).
Two Ultra 160 SCSI channels, one internal and one external (The internal
channel has two SCA2 connector ports out the front of the machine)
One IDE interface with UDMA support
One rear serial port
Two 10/100 82559 LAN Connectors
One slim-line diskette interface
LED Panel Interface
Two USB ports
Video Interface
Two PS/2 ports
®
Dual Pentium
III processors in PGA370 sockets
Up to 4 GB of registered PC-100 or PC-133 ECC SDRAM DIMMs
®
Integrated dual Intel
82559 Pro/100+ Ethernet controllers featuring PXE 2.0 option
ROM for network installation and booting of operating systems
Passive PCI riser (64-bit/66MHz) supports a low -profile and a full-length (13") PCI
card
Two Heceta 3 hardware monitoring ASIC's which work in conjunction with Web-
based management software (ASM).
Intel/AMI BIOS with extensions to enhance server management capabilities
11
