Quick Boot Disabled
Enabled (default)
After Power Failure Stays Off
Last State (default)
Power On
On Modem Ring Stay Off (default)
Power On
On LAN Stay Off
Power On (default)
On PME Stay Off (default)
Power On
st
Primary Master IDE 1 IDE (default)
nd
2 IDE
rd
3 IDE
th
4 IDE
nd
Primary Slave IDE 2 IDE (default)
rd
Secondary Master IDE 3 IDE (default)
th
Secondary Slave IDE 4 IDE (default)
st
1 to 6-th Boot Floppy (default)
Devices
IDE-HDD
ATAPI CD-ROM
ARMD-FDD
ARMD-HDD
Disabled
Intel UNDI, PXE-2.0 (LAN 1)
Intel UNDI, PXE-2.0 (LAN 2)
AIC-7899
AIC-7899
SCSI
10.6

System Management Menu

The menu bar is shown below.
Maintenance
Table 71 shows the System Management menu. This menu sets server management features.
Feature Options
Serial Features Serial Console Redirection
Intel ® SRMK2 Internet Server Technical Product Specification
Allows the BIOS to skip certain tests while booting. This
decreases the time needed to boot the system.
Determines the mode of operation if a power loss occurs.
"Stays Off" keeps system off once power is restored.
"Power On" boots the system after power is restored. "Last
State" restores the system to the same state it was in before
the power failed.
APM Mode only: Determines the action of the system when
the system power is off and the modem is ringing.
APM Mode only: Determines the action of the system when a
LAN wake up event occurs.
APM Mode only: Determines the action of the system when a
PCI Power Management Enabled wake up event occurs.
Configures the peripheral devices. Configurable options for
other IDE devices are similar to Primary Master IDE. Note that
the Primary Master/Slave IDE port is not available on the
baseboard.
Configures the boot sequence from the available devices.
IDE-HDD = Hard disk drive.
ARMD-FDD = ATAPI removable device-floppy disk drive.
Intel UNDI, PXE-2.0 = Network boot using PXE.
Channel B of the Onboard Adaptec SCSI 7899
Channel A of the Onboard Adaptec SCSI 7899
SCSI = If a SCSI device is installed, it will appear as one of the
possible boot devices with the name of device.
Main Advanced Security
Table 71: System management menu
Description
Disables or enables serial console redirection.
Disabled
Enabled (default)
Configures which COM port to use for serial
System
Boot
Managemen
t
Exit
94
