Intel SRMK2 - Server Platform - 0 MB RAM Technical Specifications page 108

08 10 99 02 27 07 41 30 00 02 00 00 00 00 00 00
08 10 99 02 26 05 34 11 00 02 00 00 00 00 00 00
>ReadSEL 0 1
Reboot -The BIOS console will reboot the system. During reboot, the BIOS will examine
BIOSControl to determine if any special action is required such as powering off the
system or booting the service partition.
CMOS/NVRAM commands
GetBootCount
The number of times the OS has tried to boot
GetLastState
This represents the last known state of the system. Possible values are:
0 Unknown (default)
1 POST
2 Emergency Mode
3 OS Booting
4 OS Initializing OS booted and started running
5 OS Running
6 OS Going Down
7 OS Down
GetLastSensor
This code represents the last known state of the sensors as monitored by either OS
instrumentation software and/or the BIOS. Possible values are:
0 Unknown (default)
1 Normal
Intel ® SRMK2 Internet Server Technical Product Specification
Figure 23: ReadSEL Example
Machine is in POST
BIOS emergency mode (console redirection)
Bootstrap about to be loaded
OS fully up
OS starting graceful shut down
OS mostly shutdown (All but essential processes and services)
108
