Table 40: Thermal considerations for components
Component
Pentium
processor
ServerWorks
CNB30LE
ServerWorks
OSB4
3.20

DC Voltage Regulation

Table 41 shows the DC output voltages that shall remain within the regulation ranges shown,
which are measured at the load end of the output connectors under all line, load, and
environmental conditions including Transients and Ripple & Noise.
Output Voltage
+3.3VDC
+ 5 VDC
+12 VDC*
-12 VDC
+ 5 VSB
* At +12V/12sec surge, 12V output regulation can go to 10%.
Intel ® SRMK2 Internet Server Technical Product Specification
Speed Maximum Temperature
®
III 1.0 GHz
933 MHz
866 MHz
800 MHz
733 MHz
®
®
Table 41: DC output voltage regulation
Range Min.
+/- 5% +3.2
+/- 5% +4.8
+/- 5% +11.40
+/- 5% -10.80
+/- 5% +4.8
70°C (thermal case)
75°C (thermal case)
80°C (thermal case)
80°C (thermal case)
80°C (thermal case)
Nom. Max.
+3.30 +3.465
+5.00 +5.25
+12.00 +12.60
-12.00 -13.20
+5.00 +5.25
Unit
Volts
Volts
Volts
Volts
Volts
53
