Primary IDE interface
Wake Headers and Power
Power connector
Wake on Ring Header
Wake on LAN Header
Add-in board
PCI bus
3.17.2.1 Peripheral Interfaces
Figure 14 shows the locations of the peripheral interface connectors.
B
C
D
A High-density diskette drive connector
B Primary IDE connector
Intel ® SRMK2 Internet Server Technical Product Specification
A
Figure 14: Peripheral connectors
Table 28: SCSI LED connector (J35)
Pin Signal Name
1 SCSI activity
2 Ground
C SCSI drive connector
D SCSI LED Header
42
