3 SRMK2 Serverboard Description

3.1 Overview

The SRMK2 serverboard features are summarized in Table 14.
Form Factor
Processor
Memory
Chipset
I/O Control
Peripheral
Interfaces
Expansion
Capabilities
BIOS
Other Features
Intel ® SRMK2 Internet Server Technical Product Specification
Table 14: SRMK2 feature summary
Serverboard dimension: 10.4" x 11.3"
®
Supports Dual Pentium III processors using PGA370 sockets
Four 168-pin dual inline memory module (DIMM) sockets
Supports only registered SDRAM DIMMs
Supports up to 4 GB of ECC, SPD Registered SDRAM DIMMs
ServerWorks® ServerSet™III LE Chipset, consists of:
ServerWorks CNB30LE North Bridge Front Side Bus Interface chip
ServerWorks OSB4 South Bridge chip
SMSC FDC37B782 I/O controller
®
Two integrated Intel 82559 10/100BASE-T Ethernet controllers
One high-density diskette drive interface for slimline diskette drive
Two U160 SCSI channels (one internal and one external wide interface connector)
One IDE interface with low profile CD support
One serial port
Two USB ports
Two PS/2 interfaces for keyboard and mouse
LED panel interface
One rear panel video interface
One 64/66 plug-in riser card expansion PCI bus slot which can fit a 2x11 riser sideband
connector supporting two PCI slots – One full length card and the other low profile.
Intel/AMI BIOS
®
Intel 8-Mbit boot block flash memory
Supports SMBIOS, Advanced Configuration and Power Interface (ACPI), and Plug and Play
(see section 14.2 Specifications for specification compliance levels)
Speaker
(2) Hardware monitor chips
Wake on Ring
Wake on LAN
SCSI LED connector
