Intel SRMK2 - Server Platform - 0 MB RAM Technical Specifications page 110

0 Modem (default)
1 Direct connect
An example of this command is presented in figure 2 below.
3 1 3 0 1 0 0 0
>GetSerialConfig
GetBIOSControl
PutBIOSControl <Value>
This value directs the BIOS to enable/disable various fail-safe BIOS features. Value is defined
as a bit field as follows:
Bit 0 Power-off (1 = power-off next boot, self-clearing)
Bit 1 Service Partition Boot (1 = boot service partition on next boot, self-clearing)
Bit 2 LAN Alerts Enable
Bit 3 Paging Enable
Bit 4 Console Redirection Enable
Bit 5 Pager Control (1 = page out on next boot, self-clearing)
Value is a decimal number. The default is 16.
GetServiceID
This code is the partition ID that the BIOS will search for and boot to when going into service
partition mode.
GetModemStr
PutModemStr <Initialization String>
Initialization String is an AT/Hayes Compatible string to send to the modem when paging or if
Emergency Console connection mode is set to modem. Length is not to exceed 64 bytes and
spaces are not allowed.
GetPagerNum
PutPagerNum <Pager Number String>
Intel ® SRMK2 Internet Server Technical Product Specification
Figure 24: GetSerialConfig example
110
