Pin
1
3
5
7
9
11
13
15
Table 27: External SCSI (Channel A) connector (J1)
Pin Signal Name
1 SDA[12]+
4 SDA[15]+
7 SDA[1]+
10 SDA[4]+
13 SDA[7]+
16 DIFFSA
19 EXT_SCSI_P19_NC
22 GRD
25 RSTA+
28 CDA+
31 SDA[8]+
34 SDA[11]+
37 SDA[14]-
40 SDA[0]-
43 SDA[3]-
46 SDA[6]-
49 GRD
52 SCSIA_5V
55 ATNA -
58 ACKA-
61 SELA-
64 IOA-
67 SDA[10]-

3.17.2 Midboard Connectors

The midboard connectors are divided into three functional groups:
Peripheral interfaces
SCSI LED Header
Internal SCSI interface
High Density Diskette Drive interface
Intel ® SRMK2 Internet Server Technical Product Specification
Table 26: Video connector (J4)
Signal Name Pin
V_RED_FB 2
V_BLUE_FB 4
GRD 6
GRD 8
TP_VIO9 10
(Not Connected) 12
V_HSYNC_R# 14
DDC2_SCL
Pin Signal Name
2 SDA[13]+
5 SDA[P1]+
8 SDA[2]+
11 SDA[5]+
14 SDA[P0]+
17 SCSIA_5V
20 GRD
23 BSYA+
26 MSGA+
29 REQA+
32 SDA[9]+
35 SDA[12]-
38 SDA[15]-
41 SDA[1]-
44 SDA[4]-
47 SDA[7]-
50 GRD
53 EXT_SCSI_P53_NC
56 GRD
59 RSTA-
62 CDA-
65 SDA[8]-
68 SDA[11]-
Signal Name
V_GREEN_FB
TP_VIO4
GRD
GRD
GRD
DDC2_SDA
V_VSYNC_R#
Pin Signal Name
3 SDA[14]+
6 SDA[0]+
9 SDA[3]+
12 SDA[6]+
15 GRD
18 SCSIA_5V
21 ATNA+
24 ACKA+
27 SELA+
30 IOA+
33 SDA[10]+
36 SDA[13]-
39 SDA[P1]-
42 SDA[2]-
45 SDA[5]-
48 SDA[P0]-
51 SCSIA_5V
54 GRD
57 BSYA-
60 MSGA-
63 REQA-
66 SDA[9]-
