5.3 Front Panel LED Indicators
Table 44 defines the LED indicators on the front panel board. The LED's are numbered below
from 1 through 9 when reading them from in front of the server from left to right.
Table 44: Front panel LEDs (DS1, DS2, DS3, DS4, DS5, DS6, DS7, DS8, DS9)
LED
Power On
(Green)
System Fault
(Amber)
Hard Disk
(Green)
LAN1 Activity/Link
(Green)
LAN1 Speed
(Green)
LAN2 Activity/Link
(Green)
LAN2 Speed
(Green)
SCSI HDD #1
Activity (Green)
SCSI HDD #0
Activity (Green)
5.4 Front Panel I/O Connector
The front panel board is connected to the SRMK2 serverboard through a high-density connector
for I/O information. See Table 36 for Front panel I/O connector (J38) signal definitions.
Intel ® SRMK2 Internet Server Technical Product Specification
This LED indicates if the system is powered on. A blinking green LED indicates the
system is in sleep mode.
This LED lights when the system has detected a system fault state.
This LED indicates when any access to the hard drive has taken place. It shows
activity from any one of three sources: Hard Disk 1, Hard Disk 2, or an external SCSI
drive that is connected to the internal SCSI activity connector
This LED lights when a successful 10/100Mb link has occurred to an Ethernet port.
Once the LED is lit, it blinks at a variable rate to indicate network activity on this
channel.
This LED lights when the LAN1 controller has detected and is configured to run at 100
Mbps operation. For 10 Mbps operation, the LED will not be lit.
This LED lights when a successful 10/100Mb link has occurred to an Ethernet port.
Once the LED is lit, it blinks at a variable rate to indicate network activity on this
channel.
This LED lights when the LAN2 controller has detected and is configured to run at 100
Mbps operation. For 10 Mbps operation, the LED will not be lit.
This LED will light Green to show SCSI HDD #1 activity.
This LED will light Green to show SCSI HDD #0 activity.
