Table 18. Primary/Secondary IDE Master/Slave Submenu Field

Menu Fields
Advanced/Primary IDE Master
Type
Drive Write Cache
LBA/Large Mode
Block(Multi-Sector
Transfer)
PIO Mode
DMA Mode
S.M.A.R.T
32 Bit Data Transfer
®
Intel Server System SR1680MV Service Guide
Settings
Not Installed Select the type of device Connected to the system.
Auto*
CD/DVD
ARMD
Disabled* Enabled: Drive Write Cache feature to be enabled to
Improve performance.
Enabled
Disabled: Drive Write Cache feature disabled to avoid the
Possibility of data loss due to a power failure.
Disabled* Disabled: Disables LBA Mode.
Auto Auto: Enables LBA Mode if the device supports it and the
device is not already formatted with LBA Mode disabled.
Disabled* Disabled: The Data transfer from and to the device occurs
one sector at a time.
Auto
Auto: The Data transfer from and to the device Occurs
multiple sectors at a time if the device supports it.
Auto Select PIO Mode.
0
1
2
3
4
Auto Select DMA Mode.
Auto: Auto detected.
Auto* S.M.A.R.T. stands for Self-Monitoring, Analysis and
Reporting Technology.
Disabled
Enables
Disabled* Enable/Disable 32-bit Data Transfer.
Enabled
Comments
73
