7
Installing the Rackmount Rail Kits
This section contains the detail instructions of installing rail kit to racks for this server.
Reverse the instillation steps to remove the rail.
The front overview and back overview of rail is shown below:
Here are some recommended screwdrivers for your reference to secure or loosen the
corresponding screws.
Tighten Screw 1
Align Pin
There are seven spring screw holes in rail to secure each spring. Spring secured in
different spring screw holes can fit to different depths for racks. The locations and the
adapt depth for racks are shown below:
®
Intel
Server System SR1680MV Service Guide
Figure 64. Overview of Rail Kit
Tighten Screw 1
Align Pin
Tighten Screw 2
Table 44.
Screw Driver
Screw Tape
TROX 25
Slotted Point
Screwdriver
Spring Secure Screw
Spring
Recommended screwdrivers
Screw Tape
Tape
Tighten Screw 2
Spring Secure Screw
Screw Driver
Tape
Cross Point
Screwdriver
Slotted Point
Screwdriver
101
