Installing a 2.5-inch Pluggable SATA HDD
Reverse the
pluggable SATA HDD.
2.5-inch Pluggable HDD Backplane
Each server board module supports one 2.5-inch pluggable HDD backplane; two HDD
backplanes share the same removal and installation procedure. For your reference, this
section provides the steps of removing and installing one 2.5-inch pluggable HDD
backplane as an example.
Figure 37 shows the location of a 2.5-inch pluggable HDD backplane on the server
chassis:
32
Figure 36. Release Screws and Lift the HDD Up
"Removing a 2.5-inch Pluggable SATA HDD"
Figure 37. 2.5-inch Pluggable HDD Backplane Location
steps to install the 2.5-inch
®
Intel
Server System SR1680MV Service Guide
