Central Processing Unit (CPU)

Each installed server node provides two surface mount LGA 1366 CPU sockets designed
for the Intel
server node can be configured to either a single- or dual-processor system.
The following figure shows the location of processors on the motherboard:
12

Figure 9. Removing the Mid-Top Cover

® ®
Xeon Processor 5500 series and Intel

Figure 10. Location of Processors

®
Xeon
1. Processor 1
2. Processor 2
®
Intel Server System SR1680MV Service Guide
®
Processor 5600 series. One
