Connector and Component Locations of HDD
Backplane
Figure 60. Connectors and Components of 2.5-inch Pluggable HDD Backplane
1. HDD 0 Fail LED (CR4)
3. HDD 1 Active LED
(CR1)
5. HDD 0 Active LED
(CR3)
7. Golden Fingers (J1)
54
2. HDD 1 Fail LED (CR2)
4. SATA 1 Connector (J3)
6. SATA 0 HDD Connector (J2)
®
Intel
Server System SR1680MV Service Guide
