To select a stroke color, style, and weight using the Property inspector:
Select an object or objects on the Stage (for symbols, first double-click to enter
1.
symbol-editing mode).
If the Property inspector is not visible, select Window > Properties.
2.
To select a color, click the triangle next to the Stroke color box and do one of the following:
3.
Select a color swatch from the palette.
Type a color's hexadecimal value in the text box.
To select a stroke style, click the triangle next to the Style pop-up menu and select an option
4.
from the menu. To create a custom style, select Custom from the Property inspector, then select
options in the Stroke Style dialog box and click OK.
Note: Selecting a stroke style other than Solid can increase file size.
To select a stroke weight, click the triangle next to the Weight pop-up menu and set the slider
5.
at the desired weight.
To apply a solid color fill using the Property inspector:
Select an object or objects on the Stage.
1.
Select Window > Properties.
2.
To select a color, click the triangle next to the Fill color box and do one of the following:
3.
Select a color swatch from the palette.
Type a color's hexadecimal value in the text box.

Working with solid colors and gradient fills in the Color Mixer

To create and edit solid colors and gradient fills, you can use the Color Mixer. If an object is
selected on the Stage, the color modifications you make in the Color Mixer are applied to
the selection.
You can create any color using the Color Mixer. You can select colors in RGB or HSB, or you
can expand the panel to use hexadecimal mode. You can also specify an alpha value to define
the degree of transparency for a color. In addition, you can select a color from the existing
color palette.
You can expand the Color Mixer to display a larger color space in place of the color bar, a split
color swatch showing the current and previous colors, and a Brightness control to modify color
brightness in all color modes.
To create or edit a solid color with the Color Mixer:
To apply the color to existing artwork, select an object or objects on the Stage.
1.
Select Window > Design Panels > Color Mixer.
2.
To select a color mode display, select RGB (the default setting) or HSB from the pop-up menu
3.
in the upper right corner of the Color Mixer.
Click the Stroke or Fill icon to specify which attribute is to be modified.
4.
Note: Be sure to click the icon, not the color box, or the color pop-up window will open.
Working with solid colors and gradient fills in the Color Mixer 77
