3-D touch probes
Coordinates of the TT 120 stylus center
relative to the machine datum
Monitoring the position of rotary axes and
parallel axes
Defining the rotary axes and parallel axes to
be monitored
KinematicsOpt: Tolerance limit for error
message in Optimization mode
664
MP6580.0 (traverse range 1)
X axis
MP6580.1 (traverse range 1)
Y axis
MP6580.2 (traverse range 1)
Z axis
MP6581.0 (traverse range 2)
X axis
MP6581.1 (traverse range 2)
Y axis
MP6581.2 (traverse range 2)
Z axis
MP6582.0 (traverse range 3)
X axis
MP6582.1 (traverse range 3)
Y axis
MP6582.2 (traverse range 3)
Z axis
MP6585
Function inactive: 0
Monitor axis positions, definable bit-coded for each axis: 1
MP6586.0
Do not monitor the position of the A axis: 0
Monitor the position of the A axis: 1
MP6586.1
Do not monitor the position of the B axis: 0
Monitor the position of the B axis: 1
MP6586.2
Do not monitor the position of the C axis: 0
Monitor the position of the C axis: 1
MP6586.3
Do not monitor the position of the U axis: 0
Monitor the position of the U axis: 1
MP6586.4
Do not monitor the position of the V axis: 0
Monitor the position of the V axis: 1
MP6586.5
Do not monitor the position of the W axis: 0
Monitor the position of the W axis: 1
MP6600
0.001 to 0.999
