Abbr. Inputs
DR2TABLE 3D-ToolComp software option: Enter the name of the
compensation value table from which the TNC is to take the
angle-dependent delta radius values DR2 (see also "3-D tool radius
compensation depending on the tool's contact angle (3D-
ToolComp software option)" on page 494)
Input range: Max. 16 characters without file extension
LAST_USE Date and time at which the TNC inserted the tool for the last time
via TOOL CALL.
Input range: 16 characters max., format internally specified: Date
= yyyy.mm.dd, time = hh.mm
Tool table: Tool data required for automatic tool measurement
For a description of the cycles for automatic tool
measurement, see the User's Manual for Cycle
Programming.
Abbr. Inputs
CUT Number of teeth (99 teeth maximum)
Input range: 0 to 99
LTOL Permissible deviation from tool length L for wear detection. If the
entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm
Input range in mm: 0 to +0.9999
Input range in inches: 0 to +0.03936
RTOL Permissible deviation from tool radius R for wear detection. If the
entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm
Input range in mm: 0 to +0.9999
Input range in inches: 0 to +0.03936
Permissible deviation from tool radius R2 for wear detection. If
R2TOL
the entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm
Input range in mm: 0 to +0.9999
Input range in inches: 0 to +0.03936
DIRECT. Cutting direction of the tool for measuring the tool during rotation
TT:R-OFFS Tool length measurement: Tool offset between stylus center and
tool center. Preset value: Tool radius R (NO ENT means R).
Input range in mm: -99999.9999 to +99999.9999
Input range in inches: -3936.9999 to +3936.9999
HEIDENHAIN iTNC 530
Dialog
Compensation-value table?
Date/time of last tool call?
Dialog
Number of teeth?
Wear tolerance: length?
Wear tolerance: radius?
Wear tolerance: Radius 2?
Cutting direction (M3 = –)?
Tool offset: radius?
