17.13 Selecting the Axes for
Generating L Blocks
Application
The axis selection input field enables you to define the current tool
position coordinates that are transferred to the G01 block To generate
a separate L block, press the ACTUAL POSITION CAPTURE key. The
axes are selected by bit-oriented definition similar to programming the
machine parameters:
Axis selection %11111: Transfer the X, Y, Z, IV, and V axes
Axis selection %01111: Transfer the X, Y, Z, and IV axes
Axis selection %00111: Transfer the X, Y and Z axes
Axis selection %00011: Transfer the X and Y axes
Axis selection %00001: Transfer the X axis
646
MOD Functions
