HEIDENHAIN ITNC 530 - CONVERSATIONAL PROGRAMMING User Manual page 320

Group name, ID no.
Active tool compensation, 200
Active transformations, 210
Path tolerance, 214
320
Number Index
2 2
2 3
3 -
1 -
2 -
1 -
2 -
3 -
4 1
4 2
4 3
4 7
4 8
4 9
5 1
5 2
5 3
6 -
7 -
8 -
Meaning
Y axis
Z axis
Programmed feed rate (–1: no feed rate programmed)
Tool radius (including delta values)
Tool length (including delta values)
Basic rotation in MANUAL OPERATION mode
Programmed rotation with Cycle 10
Active mirror axis
0: mirroring not active
+1: X axis mirrored
+2: Y axis mirrored
+4: Z axis mirrored
+64: U axis mirrored
+128: V axis mirrored
+256: W axis mirrored
Combinations = sum of individual axes
Active scaling factor in X axis
Active scaling factor in Y axis
Active scaling factor in Z axis
Active scaling factor in U axis
Active scaling factor in V axis
Active scaling factor in W axis
3-D ROT A axis
3-D ROT B axis
3-D ROT C axis
Tilted working plane active / inactive (value not equal to
0/0) in a Program Run operating mode
Tilted working plane active / inactive (value not equal to
0/0) in a Manual operating mode
Tolerance programmed with cycle 32 or MP 1096
Programming: Q Parameters
