New functions 340 49x-06
The new HR 510, HR 520 and HR 550 FS handwheels are supported
(see "Traversing with electronic handwheels" on page 528)
New software option 3-D ToolComp: 3-D tool radius compensation
depending on the tool's contact angle on blocks with surface normal
vectors (LN blocks, see "3-D tool radius compensation depending on
the tool's contact angle (3D-ToolComp software option)", page 494)
3-D line graphics is now also possible in full-screen mode (see "3-D
Line Graphics (FCL2 Function)" on page 152)
A file selection dialog for selecting files in different NC functions and
in the table view of the pallet table is available now (see "Calling any
program as a subprogram" on page 280)
DCM: Saving and restoring of fixture situations
DCM: The form for test program generation now also contains icons
and tooltips (see "Check the position of the measured fixture" on
page 394)
DCM, FixtureWizard: Touch points and probing sequence are shown
more clearly now
DCM, FixtureWizard: Designations, touch points and measuring
points can be shown or hidden as desired.(see "Operating
FixtureWizard" on page 391)
DCM, FixtureWizard: Chucking equipment and insertion points can
now also be selected by mouse click
DCM: A library with standard chucking equipment is available now
(see "Fixture templates" on page 390)
DCM: Tool carrier management (see "Tool Holder Management
(DCM Software Option)" on page 398)
