Assignment
This function sets the destination for the transferred data.
Applications:
Transferring values with Q parameter function FN15
Transferring values with Q parameter function FN16
The TNC mode of operation determines whether the PRINT or PRINT
TEST function is used:
TNC mode of operation
Program Run, Single Block
Program Run, Full Sequence
Test Run
You can set PRINT and PRINT TEST as follows:
Function
Output data via RS-232
Output data via RS-422
Save data to the TNC's hard disk
Save data to a server connected
to the TNC
Save the data in the same
directory as the program with
FN15/FN16.
File names
Data Operating mode
Values with FN15 Program Run
Values with FN15 Test Run
624
Transfer function
PRINT
PRINT
PRINT TEST
Path
RS232:\....
RS422:\....
TNC:\....
servername:\....
Vacant
File name
%FN15RUN.A
%FN15SIM.A
MOD Functions
