Example NC blocks
5 TOOL CALL 20 ...
...
13 L X... Y... R... F... M97
14 L IY-0.5 ... R... F...
15 L IX+100 ...
16 L IY+0.5 ... R... F... M97
17 L X... Y...
364
Tool with large tool radius
Move to contour point 13
Machine small contour step 13 to 14
Move to contour point 15
Machine small contour step 15 to 16
Move to contour point 17
Programming: Miscellaneous Functions
