Entering tool data in the table

You can define and store up to 30 000 tools and their tool data in a tool
table. In Machine Parameter 7260, you can define how many tools are
to be stored by the TNC when a new table is set up. Also see the
Editing Functions later in this chapter. In order to be able to assign
various compensation data to a tool (indexing the tool number),
MP7262 must not be equal to 0.
You must use tool tables if
you wish to use indexed tools such as stepped drills with more than
one length compensation value (see page 178)
your machine tool has an automatic tool changer
you want to measure tools automatically with the TT 130 touch
probe (see the Touch Probe Cycles User's Manual)
you want to rough-mill the contour with Cycle 22, (see "User's
Manual for Cycles, ROUGH-OUT")
you want to work with Cycles 251 to 254 (see "User's Manual for
Cycles," Cycles 251 to 254)
you want to work with automatic cutting data calculations.
Tool table: Standard tool data
Abbr. Inputs
Number by which the tool is called in the program (e.g. 5, indexed:
T
5.2).
NAME Name by which you call the tool in the program.
Input range: 16 characters max., only capital letters, no space
characters)
L Compensation value for tool length L
Input range in mm: -99999.9999 to +99999.9999
Input range in inches: -3936.9999 to +3936.9999
R Compensation value for the tool radius R
Input range in mm: -99999.9999 to +99999.9999
Input range in inches: -3936.9999 to +3936.9999
Tool radius 2 for toroid cutters (only for 3-D radius compensation
R2
or graphical representation of a machining operation with
spherical or toroid cutters)
Input range in mm: -99999.9999 to +99999.9999
Input range in inches: -3936.9999 to +3936.9999
DL Delta value for tool length L.
Input range in mm: -99.9999 to +99.9999
Input range in inches: -3.937 to +3.937
172
Dialog
-
Tool name?
Tool length?
Tool radius R?
Tool radius R2?
Tool length oversize?
Programming: Tools
