HEIDENHAIN ITNC 530 - CONVERSATIONAL PROGRAMMING User Manual page 318

Group name, ID no.
Data from the tool table, 50
318
Number Index
10 -
11 -
12 -
13 -
14 -
15 -
1 Tool no.
2 Tool no.
3 Tool no.
4 Tool no.
5 Tool no.
6 Tool no.
7 Tool no.
8 Tool no.
9 Tool no.
10 Tool no.
11 Tool no.
12 Tool no.
13 Tool no.
14 Tool no.
15 Tool no.
16 Tool no.
17 Tool no.
18 Tool no.
19 Tool no.
20 Tool no.
21 Tool no.
22 Tool no.
23 Tool no.
Meaning
Feed rate for milling in active fixed cycle
Direction of rotation for active fixed cycle
Dwell time for active fixed cycle
Thread pitch for Cycles 17, 18
Milling allowance for active fixed cycle
Direction angle for rough out in active fixed cycle
Tool length
Tool radius
Tool radius R2
Oversize for tool length DL
Oversize for tool radius DR
Oversize for tool radius DR2
Tool inhibited (0 or 1)
Number of the replacement tool
Maximum tool age TIME1
Maximum tool age TIME2
Current tool age CUR. TIME
PLC status
Maximum tooth length LCUTS
Maximum plunge angle ANGLE
TT: Number of tool teeth CUT
TT: Wear tolerance for length LTOL
TT: Wear tolerance for radius RTOL
TT: Rotational direction DIRECT (0=positive/–
1=negative)
TT: Offset in plane R-OFFS
TT: Offset for length L-OFFS
TT: Break tolerance for length LBREAK
TT: Break tolerance for RBREAK radius
PLC value
Programming: Q Parameters
