18.3 Technical Information

Explanation of symbols
Standard
Axis option
Software option 1
Software option 2
User functions
Short description
Program entry
Position data
Tool compensation
Tool tables
Cutting-data tables
Constant contour speed
Parallel operation
3-D machining
(software option 2)
Rotary table machining
(software option 1)
678
Basic version: 3 axes plus spindle
Fourth NC axis plus auxiliary axis
or
8 additional axes or 7 additional axes plus 2nd spindle
Digital current and shaft speed control
HEIDENHAIN conversational format, with smarT.NC and as per ISO
Nominal positions for lines and arcs in Cartesian coordinates or polar coordinates
Incremental or absolute dimensions
Display and entry in mm or inches
Display of the handwheel path during machining with handwheel superimpositioning
Tool radius in the working plane and tool length
Radius compensated contour look ahead for up to 99 blocks (M120)
Three-dimensional tool-radius compensation for subsequent changing of tool data
without having to recalculate the program
Multiple tool tables with up to 30 000 tools
Cutting data tables for automatic calculation of spindle speed and feed rate from tool-
specific data (cutting speed, feed per tooth)
With respect to the path of the tool center
With respect to the cutting edge
Creating a program with graphical support while another program is being run
Motion control with minimum jerk
3-D compensation through surface normal vectors
Using the electronic handwheel to change the angle of the swivel head during program
run without affecting the position of the tool point (TCPM = Tool Center Point
Management)
Keeping the tool normal to the contour
Tool radius compensation normal to the direction of traverse and the tool direction
Spline interpolation
Programming of cylindrical contours as if in two axes
Feed rate in distance per minute
Tables and Overviews
