Overview Tables
Machining cycles
Cycle
Cycle designation
number
7
Datum shift
8
Mirror image
9
Dwell time
10
Rotation
11
Scaling factor
12
Program call
13
Oriented spindle stop
14
Contour definition
19
Tilting the working plane
20
SL II contour data
21
SL II pilot drilling
22
SL II rough out
23
Floor finishing SL II
24
Side finishing SL II
25
Contour train
26
Axis-specific scaling
27
Cylinder surface
28
Cylindrical surface slot
29
Cylinder surface ridge
30
Run 3-D data
32
Tolerance
39
Cylinder surface external contour
200
Drilling
201
Reaming
202
Boring
203
Universal drilling
DEF
CALL
active
active
